CSI: CAD Standards Implementation
Instructional demo    IT15277
Sam Lucido
[up-f8BznD4bT6aNEa43921Tfg%3D%3D-firstName] [up-f8BznD4bT6aNEa43921Tfg%3D%3D-lastName]
[up-f8BznD4bT6aNEa43921Tfg%3D%3D-badges]
[up-f8BznD4bT6aNEa43921Tfg%3D%3D-firstName] [up-f8BznD4bT6aNEa43921Tfg%3D%3D-lastName]
[up-f8BznD4bT6aNEa43921Tfg%3D%3D-jobTitle]
[up-f8BznD4bT6aNEa43921Tfg%3D%3D-company]
[up-f8BznD4bT6aNEa43921Tfg%3D%3D-metrics]
Share Share
Comment Comment
Bookmark Bookmark
You must be signed in for this action Sign in
Close
mXebSIi7tGZwe0U34xMDoxOjBrO-I4W8
Collapse Expand

Description

Did you know that AutoCAD software has a CAD Standards Manager? Yes, there is a panel on the Ribbon under the manage tab where you can find the CAD Standards panel. Consistency in design and drafting are very important for maintaining and sharing drawings internally and externally in AutoCAD software. The CAD standards manager can help you check, correct, and maintain standards within your company. In this class, we will review the CAD Standards panel on the ribbon and explore how you can use that tool to capitalize on your standards within your company. At the end of this class you will be able to configure template files for standards, use the batch checker to create a violation report, and understand the use of the layer translator. You will bring back knowledge about how to help your employer move forward in the production of standard work. This session features AutoCAD and AutoCAD Civil 3D.

Key Learnings

  • Understand how to use and configure CAD Standards Manager tools in AutoCAD
  • Learn how to identify, change, and create standards files (.DWS) to define your company CAD standards
  • Learn how to associate a CAD Standards file with a drawing, and check the drawing for standards compliance
  • Learn how to use the Layer Translator to automate the process of changing layers to adhere to your company standards

Speakers

I am a CAD Services Manager and Civil Designer with Haley & Aldrich, Inc. I have 25+ years of experience in computer-aided design and drafting, CAD standards, Customization, and Training Programs using Autodesk software. I present workshops on CAD productivity to managers and users while providing support on architectural, civil, mechanical, and structural design projects. I have authored 10 articles in AUGIWorld Magazine and have been a top rated speaker at Autodesk University for the past 5 years. I am the owner and operator of CADproTips.com, and Expert Elite Member, and professionally certified in Autodesk AutoCAD.
