Instructional Demo    CI10541
Addressing Complex Designs with AutoCAD Civil 3D
GFTGkXQ1lvFEAkA34xMDoxOjBrO-I4W8
Share
Comment
Bookmark
You must be signed in for this action Sign in
Close
Collapse Expand

Description

Most roadway designs become complex due to the situations involved in the location of the design. Straight roads and even intersections are not likely in real-world situations. This session will discuss what options are available, and when or when not to use certain tools to address the design needs of projects.

Key Learnings

  • Learn how to use the alignment and profile relationship differently
  • Learn how to make grading an appropriate solution in some situations
  • Discover the use of a "setup" corridor for precise targeting
  • Learn how to deal with the real-world complexities of an AutoCAD Civil 3D project
