Toolbox 🧰

This Addin contains 8 sets of tools.

MEP group for connecting MEP Elements and Splitting Ducts & Pipes.

Piping group for Riser connections 90 and 45 degrees, Sizing Fire Network, and Pipes Supports.

Ducting for setting the value of ASHRAE losses and Ducts Supports.

Electrical for families flipping, Converting Detail Lines to Wires and Tray Supports.

Structural for joining elements, Ceating MEP Openings

Coordination Tools to Zoom, 3D Box, IDs of Linked Elements, Rotate section boxes, and Measure distances,Batch Add and Reload Links

Parameters to Numbering, Set & Copy parameter Values, and Transfer Shared Parameters.

Schedules to Extract and Filter data (local & Linked) & Edit with Excel and Export Excel.
