Naviate Rebar streamlines 3D reinforcement detailing in Autodesk Revit.
It helps structural engineers and rebar detailers work faster, reduce errors, and confidently handle complex concrete projects.
With connected, automated workflows, Naviate Rebar enables the creation of construction‑ready reinforcement models - so you can spend less time on manual tasks and more time on design quality and coordination.
Key capabilities
Naviate Rebar reduces repetitive work, minimizes detailing errors, and supports efficient delivery of high‑quality reinforcement models in Revit.
Naviate Rebar helps structural detailers efficiently create reinforcement for typical building elements such as slabs, beams, columns, and walls. Automated workflows reduce manual modeling and ensure consistent results across the entire building structure.
In building projects with many similar structural elements, Naviate Rebar allows detailers to apply the same reinforcement settings to multiple elements at once. This significantly shortens detailing time while maintaining uniform reinforcement layouts.
Naviate Rebar supports the delivery of accurate, constructible reinforcement models tailored for building projects. By reducing manual adjustments, the risk of detailing errors is minimized, improving coordination between design and construction teams.
Naviate Rebar helps detailers create clash‑free reinforcement by applying intelligent, rule‑based placement directly in Revit. And the Rebar Collision tool can detecting collisions between rebars within structural elements, the tool ensures correct placement and distribution, improving model quality and reducing coordination issues before construction.
