App Helps Arrange and Align Objects in AutoCAD

align objects in AutoCAD

It’s one thing to position and move. But it can be challenging to arrange and align objects in AutoCAD, depending on the complexity. The Arrange app in the Autodesk App Store makes it a bit easier.

According to the developer PrimoCAD, here are a few things you can do:

  • Align objects where the centers or edges of their bounding boxes are lined up to one another
  • Distribute objects where they are spaced based on the centers or edges of their bounding boxes at equal horizontal or vertical intervals
  • Align objects with respect to each other or a specific reference point

The app is free and also compatible with the Architecture, Electrical, Mechanical, MEP, and Plant 3Dspecialized toolsets. You can check it out and download it here.

Check out the entire series for more indispensable AutoCAD apps available on the Autodesk App Store.
