Instructional Demo    GEN11219
The Most Dynamic Class on the Block—Creating Dynamic Blocks in AutoCAD
n0d1GU7_zCmdLvW34xMDoxOjBrO-I4W8
Share
Comment
Bookmark
You must be signed in for this action Sign in
Close
Collapse Expand

Description

Why should you be using dynamic blocks? Quite simply, dynamic blocks can greatly reduce the number of blocks in your library, improving your efficiency. While it does take a little more time up front to create a dynamic block, the timesavings on the back end are well worth the effort! Even better news: if you are a proficient user of AutoCAD software, you should have no problem converting those boring, static blocks into shiny, new, dynamic blocks.


Key Learnings

  • Learn how to create Dynamic Blocks with the following abilities: stretch, mirror, array, rotate, align, multiple insertion points
  • Learn how to limit block variations through lists and increments
  • Learn how to apply constraints and parameters to control block behavior
  • Learn how to implement Block Tables as well as the Lookup Action to quickly select the desired block iteration
