Designers can now create custom parametric portals to tunnels providing more flexibility.

Reduce risks by specifying tunnel regions to disallow segment seams in successive rings and avoid points of structural weakness.

Access Revit Family bored segment in the content picker for InfraWorks tunnels.

Reduce design time using Revit family-based parametric components, including 2D extruded components as well as 3D girders.

Hover over vertices on the clipping plane in the new point elevation option and see a visual cue that indicates which vertex’ elevation is then being displayed in the dynamic dimension marker, along with a leader line.

Select parametric bridge and tunnel content including cross frames, bearings and 2D sliced based geometry in the Style Palette and check for updates, then apply all the changes to all instances in the InfraWorks model.

Assign more specific Revit categories for Inventor components and assemblies when importing into the InfraWorks style palette for quality documentation of your designs.

See all expected and optional parameters in InfraWorks for all parametric component types in the style palette.

Bi-directional workflow enables a more efficient process for the management of changes to steel girder dimensions during the iteration of bridge design.

Isolate geometry of interest to better understand bridge and tunnel designs.

Edit bridge decks and girders independently of other bridge components.
