Assess superelevation, road assembly, and cut-and-fill engineering details of your road design in cross-section form.
Design roads using smart components like lanes, curbs, and sidewalks that can each be configured separately.
See more detail in your existing and proposed ground surfaces by displaying contours and controlling the interval.
Calculate quantities for bridges, intersections, and roundabouts, with the flexibility to limit quantities to certain station ranges within a road.
Danish engineering firm COWI uses InfraWorks to create 3D models that include existing geographical conditions—and quickly wins the E16 Scandinavian highway project.
In this road-widening project, Australian infrastructure and environmental services company Cardno used visualizations to let stakeholders dynamically explore proposed designs.
Norwegian firm Rambøll Sweco contributed to a project to lay 75 km of double track between Sørli and Brumunddal in Norway. Using BIM, the project team overcame terrain challenges and got approvals from more than 100 stakeholders.
Create and model roundabout designs
InfraWorks + AutoCAD Civil 3D
Create and edit a geometrically accurate roundabout and assess design options in InfraWorks. In AutoCAD Civil 3D, perform more-detailed engineering, applying additional features and proper standards to your design.
Establish existing conditions with point clouds
InfraWorks + ReCap
Generate an intelligent model of your project environment with existing data in InfraWorks. Augment the model with point cloud data from ReCap for a more real-world context of the environment.
